Applied Breather Controller With TimeStamp Datalog
Applied Breather controller is one of our products which is well designed and developed for the purpose of Transformer Breather Compartment’s dryer application. ABR100 controls the drying ,regeneration using preset timers, input/output control relays. It also takes input from a humidity sensor for triggering the regeneration
Features
- Electrical direct controls using relays
- Web browser–based application
- RS485 connectivity
- Ethernet speed: 10 Mbps
- Parameter backup using supercapacitor during power-off
- Datalogging with timestamp support
Technical Specifications
| Parameter | Specification | |||
| Supply Voltage | +24 VDC | |||
| Current Rating | +24 VDC max @ 200 mA | |||
| Operating Temperature | -45°C to +60°C | |||
| Analog Input | 4–20 mA / 0–5 V | |||
| Analog Output | 1 | |||
| Digital Input | 2 (+24 VDC) | |||
| Digital Output | 12 | |||
| Relay Current Rating | 10 A @ 250 VAC | |||
| Serial Communication | RS485 | |||
| Protocol | I2C / MODBUS RTU / TCP | |||
| Board Dimension (L × W) | 155 × 140 mm | |||
